Genomic Analysis of Rhodococcus sp. Br-6, a Bromate Reducing Bacterium Isolated From Soil in Chiba, Japan

Kohei Ito1,2, Masafumi Harada1,2, Nobuyoshi Nakajima3, Shigeki Yamamura3,4, Masaru Tomita1,2, Haruo Suzuki1,2 Corresponding address, Seigo Amachi5

1. Institute for Advanced Biosciences, Keio University, Tsuruoka, Yamagata, Japan
2. Faculty of Environment and Information Studies, Keio University, Fujisawa, Kanagawa, Japan
3. Center for Environmental Biology and Ecosystem Studies, National Institute for Environmental Studies, Tsukuba, Ibaraki, Japan
4. Center for Regional Environmental Research, National Institute for Environmental Studies, Tsukuba, Ibaraki, Japan
5. Graduate School of Horticulture, Chiba University, Matsudo City, Chiba, Japan

Ito K, Harada M, Nakajima N, Yamamura S, Tomita M, Suzuki H, Amachi S. Genomic Analysis of Rhodococcus sp. Br-6, a Bromate Reducing Bacterium Isolated From Soil in Chiba, Japan. J Genomics 2018; 6:122-126. doi:10.7150/jgen.27741. https://www.jgenomics.com/v06p0122.htm
Other styles

File import instruction


Graphic abstract

Bromate is a byproduct of the ozone disinfection of drinking water. It is a genotoxic carcinogen and causes renal cell tumors in rats. Physicochemical removal of bromate is very difficult, making microbial reduction of bromate to bromide a promising approach to eliminate bromate from water. Rhodococcus sp. Br-6, isolated from soil, can efficiently reduce bromate by using acetate as an electron donor. We determined the draft genome sequence of Rhodococcus sp. Br-6 for the potential practical application of the bromate-reducing bacterium. Core genome phylogeny suggests that the Br-6 strain is most closely related to R. equi. The Br-6 genome contains genes encoding multiple isoforms of diaphorase, previously found to be involved in Br-6-mediated bromate reduction. The genes identified in the present study could be effective targets for experimental studies of microbial bromate reduction in the future.

Keywords: Bromate reducing bacterium, Rhodococcus sp. Br-6, Genome, Phylogeny, Diaphorase.


Chemical compounds are purified by multiple treatment steps at water treatment plants. Common filtration treatments do not remove fungal odor and agricultural chemicals so ozone treatment is commonly used. Bromate is a disinfection byproduct of ozone treatment and is formed from the bromide ion [1]. Bromate is a genotoxic carcinogen that causes renal cell tumors in rats. However, as long as ozone treatment is carried out, it is very difficult to completely remove bromate from the water. The microbial reduction of bromate to bromide is a promising way to remove bromate from drinking water and bromate reduction in biologically activated carbon (BAC) filters can reduce bromate [2]. Several studies have indicated that bacterial communities catalyze bromate reduction. However, to date, few bacteria from such communities have been isolated as pure cultures, and the mechanism of bacterial bromate reduction has not been elucidated. A soil bacterium Rhodococcus sp. Br-6 was previously isolated from soil in Matsudo-city, Chiba, Japan [3]. Strain Br-6 completely reduced 250 μM bromate within 4 days in the presence of acetate as an electron donor under microaerophilic conditions. Interestingly, the bromate reduction rate of strain Br-6 was much faster than that described for other bromate-reducing bacteria [3].

The genus Rhodococcus comprises more than 40 species, and is widely distributed in the environment [4]. Rhodococcus species have been used for various biotechnological applications including the production of acrylates and bioactive steroids, and fossil fuel desulfurization due to their biodegradative abilities [5]. We determined the draft genome sequence of Rhodococcus sp. Br-6 to understand its detailed metabolism and for the future practical application of bromate-reducing bacteria. We used multiple databases to identify genes involved in bromate reduction by strain Br-6 and assigned functional protein annotations. We also compared the genome sequence of Br-6 with that of sequenced Rhodococcus strains to reconstruct the genome-based phylogenetic tree and to assess the conservation of Br-6 genes in other Rhodococcus genomes.

Materials and Methods

Genome sequencing and assembly

Rhodococcus sp. Br-6 was grown aerobically in a minimal salt medium containing acetate as the carbon source [3], and DNA was extracted using a DNeasy blood and tissue kit (Qiagen, Hilden, Germany). Whole-genome sequencing was performed using the Illumina MiSeq sequencing platform as per manufacturer's instructions. The sequencer produced 300-bp paired-end reads that were obtained from 550-bp inserts. Quality control and genome assembly were performed as described previously [6].

Genome annotation

The genome was annotated using Prokka v1.11 [7]. A total of 5,186 protein coding DNA sequences (CDSs) were predicted using Prokka for the Br-6 strain. We performed similarity searches of the 5,186 Br-6 proteins against the UniProt Reference Clusters UniRef90 (Release: 07-Sep-2016; Number of clusters: 44,448,796) [8] using BLASTP [9] with the E value cutoff of 1e-05 and assigned the most similar (best hit) protein sequence information. The genome was also annotated using KAAS (KEGG Automatic Annotation Server) [10] for which gene data sets from three Rhodococcus spp. (R. jostii, R. erythropolis PR4, and R. opacus B4) and the default set of organisms (abbreviated as “hsa, dme, cel, ath, sce, cho, eco, nme, hpy, rpr, bsu, lla, cac, mge, mtu, ctr, bbu, syn, bth, dra, aae, mja, ape, rha, rer, and rop” at http://www.genome.jp/tools/kaas/) were selected.

Comparative genomic analysis

For comparative analysis with Rhodococcus sp. Br-6, RefSeq data for the genome sequences of Rhodococcus species including R. defluvii and R. equi [11][12] (Table 1) were downloaded from NCBI FTP Site (ftp://ftp.ncbi.nlm.nih.gov/genomes/) [13] in December 2016.

Homologous groups of genes (representing “protein families”) from multiple Rhodococcus genomes were built using the pan-genome analysis pipeline Roary with the minimum BLASTP percentage identity of 80 [14]. Nucleotide sequence alignments for genes present in a single copy in every genome (“core-genome”) were produced using MAFFT [15]. A phylogenetic tree for the concatenated core gene alignment was reconstructed using the GTR+CAT model of FastTree version 2.1.9 [16]. Based on previous phylogenetic studies [12][17], R. triatomae, R. jostii, R. opacus, and R. erythropolis were used as an outgroup for tree rooting. The “drop.tip” function of the package APE (version 5.0) in R (version 3.4.3) was used to remove the outgroup of the phylogenetic tree. The phylogenetic tree was drawn using FigTree version 1.4.3 (http://tree.bio.ed.ac.uk/software/figtree/).

To assess the conservation of the protein-encoding genes of strain Br-6 in other Rhodococcus strains, we performed TBLASTN searches with the E-value cutoff of 1e-5 [9] to compare strain Br-6 protein sequences with whole nucleotide sequences of 13 Rhodococcus strains. This approach can detect genes that were missed due to differences in gene finding algorithms.

 Table 1

Genomic features of the Rhodococcus strains analyzed

Accession No.Organism% GCSize (bp)CDS
GCF_000196695.1R. equi 103S68.85,043,1704,512
GCF_000738775.1R. defluvii strain Ca1168.75,134,3374,791
GCF_002094305.1R. equi strain DSM 2030768.85,199,7104,803
This studyRhodococcus sp. Br-668.75,496,4765,186
GCF_000341795.1R. triatomae BKS 15-1469.05,824,3495,269
GCF_000454045.1R. erythropolis CCM259562.56,371,4215,828
GCF_000696675.2R. erythropolis R13862.36,806,5066,130
GCF_000975175.1R. erythropolis strain BG4362.36,865,2056,158
GCF_000010105.1R. erythropolis PR462.36,895,5386,437
GCF_001685605.1R. opacus strain 1CP67.18,637,5357,921
GCF_000010805.1R. opacus B467.68,834,9398,203
GCF_000599545.1R. opacus PD63067.29,169,0328,942
GCF_000014565.1R. jostii RHA167.09,702,7379,145

% GC: G+C content defined as 100 × (G+C)/(A+T+G+C).

CDS: the number of protein-coding DNA sequences.

Results and Discussion

Genomic features

The draft genome sequence of Rhodococcus sp. Br-6 contains 23 contigs consisting of 5,496,476 bp, with a G+C content of 68.66 % (Table 1). Among the 13 Rhodococcus strains analyzed, genome size (Mb) and G+C content (%) varied from 5.0 (R. equi 103S) to 9.7 (R. jostii), and 62 (R. erythropolis) to 69 (R. triatomae), respectively. The genome size and G+C content of strain Br-6 were similar to those of the ingroup taxa (R. equi and R. defluvii).

Genome phylogeny

Previously, based on the 16S rRNA gene sequence analysis, the Br-6 strain was reported to be most closely related to R. equi [3]. In the present study, 839 core genes were used to infer the phylogenetic relationships between the 13 Rhodococcus strains. The phylogenetic tree, inferred from concatenation of the core genes (Figure 1), demonstrated that strain Br-6 and R. equi strains 103S and DSM 20307T formed a clade to which R. defluvii is the sister species. The core genome phylogeny suggests that strain Br-6 belongs to the species R. equi.

Gene conservation

We performed TBLASTN searches [9] to assess the conservation of Br-6 genes in other Rhodococcus genomes. Of the 5,167 protein-coding genes detected in the Br-6 genome, 4,716 were conserved in all R. equi strains (103S and DSM 20307T), and 3,671 were conserved in all the Rhodococcus strains examined. The largest numbers of Br-6 genes were conserved in the R. equi strains, ranging from 4,753 to 4,763, followed by R. defluvii with 4,452, and finally the outgroup, ranging from 4,178 (R. triatomae) to 4,295 (R. jostii). Thus, the conservation of Br-6 genes in the Rhodococcus strains roughly follows the pattern of their phylogenetic relationships (Figure 1).

Gene functions

The draft genome sequence of strain Br-6 contained 5,186 protein coding DNA sequences (CDS), of which 1,452 were functionally unknown, with a product name of “hypothetical protein” (Table S1). Of the 5,186 proteins, 4,947 (95.4%) matched with 4,894 unique records in the UniRef90 database, and 2,044 (39.4%) matched with 1,481 unique KEGG orthology (KO) identifiers.

We searched for genes involved in various biological functions of strain Br-6. The Br-6 genome contained at least 13 genes coding for c-type cytochromes and at least 19 genes putatively involved in arsenic resistance or arsenic metabolism: several genes encoding HTH-type, ArsR family transcriptional regulators, arsB encoding the membrane arsenic pump protein (locus_tag: Br6_00718), aioB encoding the arsenite oxidase subunit AioB precursor (locus_tag: Br6_00766), arsA encoding the arsenic pump-driving ATPase (locus_tag: Br6_00780 and Br6_04451), arsC encoding the arsenate reductase (locus_tag: Br6_01479), and a cluster of three genes (locus_tag: Br6_04407, Br6_04408, and Br6_04409; UniProt: E4WCD3, E4WCD4, and E4WCD5) which appear to form the arsRBC operon [18]. The draft genome contains a nitrate reductase gene cluster (locus_tag: Br6_04375, Br6_04376, Br6_04377, and Br6_04378) and denitrification regulatory proteins (locus_tag: Br6_04870 and Br6_04921), but does not contain nitrogenase genes. As expected by the fact that Rhodococcus is non-motile, the Br-6 genome did not contain any genes involved in motility.

 Figure 1

Phylogenetic tree obtained from a concatenated nucleotide sequence alignment of the 868 core genes of 13 Rhodococcus strains. The horizontal bar at the base of the figure represents 0.008 substitutions per nucleotide site. All the internodes exhibited highest local support values of 1.0.

J Genomics Image

(View in new window)

 Table 2

Br-6 strain lpdC gene homologues identified by BLASTP search.

BLAST search statistics
locus_tagGeneProductAlignment length% IdentityE-value
Br6_03586lpdCdihydrolipoyl dehydrogenase467100.00
Br6_02233mtrmycothione reductase47531.21.E-56
Br6_00169lpdANAD(P)H dehydrogenase47229.55.E-51
Br6_01549merAmercuric reductase48728.33.E-39
Br6_00125cdrcoenzyme A disulfide reductase34728.01.E-21
Br6_00870ahpFalkyl hydroperoxide reductase subunit F20129.43.E-08
Br6_03974trxB_2thioredoxin reductase33323.71.E-07
Br6_03365thcD_3rhodocoxin reductase19928.62.E-07
Br6_00086camAputidaredoxin reductase19126.26.E-07
Br6_03025yumCferredoxin--NADP reductase 232025.02.E-06
Br6_00577thcD_1rhodocoxin reductase23928.52.E-06

Tamai et al. (2016) suggested that diaphorase is involved in bromate reduction by strain Br-6, and that strain Br-6 has multiple isoforms of diaphorase [3]. Some dihydrolipoyl dehydrogenase (DLD) enzymes have NADH-dependent diaphorase activity [19]. The Br-6 genome contains the lpdC gene, which encodes DLD (locus_tag: Br6_03586; UniProt: E4W8R5). The DLD protein sequence was used as a query in a BLASTP search (E-value < 1e-5) against all the strain Br-6 predicted protein sequences to identify DLD homologues. The lpdC protein has low percentage identity (ranging from 25% to 31%) with all 10 reductase encoding homologs (Table 2), including the lpdA gene, annotated as “NAD(P)H dehydrogenase” (locus_tag: Br6_00169) or “flavoprotein disulfide reductase” (UniProt: E9T344), and the merA gene, annotated as "mercuric reductase" (Br6_01549) or "putative dihydrolipoyl dehydrogenase" (UniProt: E4WE66). The lpdC, lpdA, and merA genes were also annotated as “dihydrolipoamide dehydrogenase [EC:]” (KEGG: K00382). These results suggest that these homologous genes encode multiple diaphorase isoforms. The genes identified here could be effective targets for future experimental studies.

Nucleotide sequence accession number

The whole Rhodococcus sp. Br-6 genome shotgun sequence has been deposited at DDBJ/EMBL/GenBank under the accession number BDGK00000000. The version described in this paper is the second version, BDGK02000000.

Supplementary Material

Table S1. Rhodococcus sp. strain Br-6 genes. The columns are as follows: locus_tag, length in amino acids (Laa), KEGG orthology identifiers (ko), gene and product names, and the most similar sequence annotation in the UniRef90 database (FASTA header and organism name).



We thank Nao Takeuchi for providing helpful comments about the manuscript. This work was supported in part by research funding from Keio University, Yamagata Prefecture and Tsuruoka City. Computational resources were provided by the Data Integration and Analysis Facility, National Institute for Basic Biology.

Conflicts of Interest

The authors declare that there are no conflicts of interest.


1. von Gunten U. Ozonation of drinking water: Part II. Disinfection and by-product formation in presence of bromide, iodide or chlorine. Water Res. 2003;37(7):1469-1487

2. Kirisits MJ, Snoeyink VL, Inan H, Chee-sanford JC, Raskin L, Brown JC. Water quality factors affecting bromate reduction in biologically active carbon filters. Water Res. 2001;35(4):891-900

3. Tamai N, Ishii T, Sato Y. et al. Bromate Reduction by Rhodococcus sp. Br-6 in the Presence of Multiple Redox Mediators. Environ Sci Technol. 2016;50(19):10527-10534

4. Larkin MJ, Kulakov LA, Allen CC. Biodegradation and Rhodococcus - masters of catabolic versatility. Curr Opin Biotechnol. 2005;16(3):282-290

5. Gürtler V, Mayall BC, Seviour R. Can whole genome analysis refine the taxonomy of the genus Rhodococcus?. FEMS Microbiol Rev. 2004;28(3):377-403

6. Yuliana T, Nakajima N, Yamamura S, Tomita M, Suzuki H, Amachi S. Draft Genome Sequence of Roseovarius sp. A-2, an Iodide-Oxidizing Bacterium Isolated from Natural Gas Brine Water, Chiba, Japan. J genomics. 2017;5:51-53

7. Seemann T. Prokka: rapid prokaryotic genome annotation. Bioinformatics. 2014;30(14):2068-2069

8. Suzek BE, Wang Y, Huang H, McGarvey PB, Wu CH, UniProt Consortium. UniRef clusters: a comprehensive and scalable alternative for improving sequence similarity searches. Bioinformatics. 2015;31(6):926-932

9. Boratyn GM, Camacho C, Cooper PS. et al. BLAST: a more efficient report with usability improvements. Nucleic Acids Res. 2013;41(Web Server issue):W29-33

10. Moriya Y, Itoh M, Okuda S, Yoshizawa AC, Kanehisa M. KAAS: an automatic genome annotation and pathway reconstruction server. Nucleic Acids Res. 2007;35(Web Server):W182-W185

11. Letek M, González P, Macarthur I. et al. The genome of a pathogenic rhodococcus: cooptive virulence underpinned by key gene acquisitions. PLoS Genet. 2010;6(9):e1001145

12. Anastasi E, MacArthur I, Scortti M, Alvarez S, Giguère S, Vázquez-Boland JA. Pangenome and Phylogenomic Analysis of the Pathogenic Actinobacterium Rhodococcus equi. Genome Biol Evol. 2016;8(10):3140-3148

13. NCBI Resource Coordinators. Database resources of the National Center for Biotechnology Information. Nucleic Acids Res. 2016;44(D1):D7-D19

14. Page AJ, Cummins CA, Hunt M. et al. Roary: rapid large-scale prokaryote pan genome analysis. Bioinformatics. 2015;31(22):3691-3693

15. Katoh K, Misawa K, Kuma K, Miyata T. MAFFT: a novel method for rapid multiple sequence alignment based on fast Fourier transform. Nucleic Acids Res. 2002;30(14):3059-3066

16. Price MN, Dehal PS, Arkin AP, Rojas M, Brodie E. FastTree 2 - Approximately Maximum-Likelihood Trees for Large Alignments. Poon AFY, ed. PLoS One. 2010;5(3):e9490

17. Creason AL, Davis EW, Putnam ML, Vandeputte OM, Chang JH, Chang JH. Use of whole genome sequences to develop a molecular phylogenetic framework for Rhodococcus fascians and the Rhodococcus genus. Front Plant Sci. 2014;5:406

18. Achour-Rokbani A, Cordi A, Poupin P, Bauda P, Billard P. Characterization of the ars gene cluster from extremely arsenic-resistant Microbacterium sp. strain A33. Appl Environ Microbiol. 2010;76(3):948-955

19. Kianmehr A, Mahdizadeh R, Oladnabi M, Ansari J. Recombinant expression, characterization and application of a dihydrolipoamide dehydrogenase with diaphorase activity from Bacillus sphaericus. 3 Biotech. 2017;7(2):153
